Top Fly: Br 2140
| Company | Top Fly |
| Type | Single |
| Eye Position | Turned down |
| Shank Style | Straigth |
| Barb | Barbless |
| Color |
Black Nickel
|
| Usages |
Dry
Nymph Trout Grayling Freshwater Spider |
| Sizes | 20 18 16 14 12 10 |
Sizes
| Length | 13.79 mm |
| Shank Length | 8.48 mm |
| Throat | 5.97 mm |
| Gape | 6.18 mm |
| Eye Width | 1.53 mm |
| Wire Thickness | 0.51 mm |
| Length | 15.26 mm |
| Shank Length | 9.71 mm |
| Throat | 6.87 mm |
| Gape | 6.55 mm |
| Eye Width | 1.61 mm |
| Wire Thickness | 0.49 mm |
Similar hooks
Hooks found to have similar properties as this hook (matched per hook size, ordered by total length).
The left number in each column is this value for that size.
| Size | Hook | Length | Shank Length | Gape | Throat | Wire |
|---|---|---|---|---|---|---|
| 12 | H480BL | 13.79 -> 13.39 | 8.48 -> 8.09 | 6.18 -> 6.00 | 5.97 -> 6.39 | 0.51 -> 0.61 |
| 12 | R90 | 13.79 -> 13.43 | 8.48 -> 8.14 | 6.18 -> 5.88 | 5.97 -> 6.57 | 0.51 -> 0.68 |
| 12 | BL 454 | 13.79 -> 13.69 | 8.48 -> 8.66 | 6.18 -> 6.58 | 5.97 -> 6.12 | 0.51 -> 0.52 |
| 12 | H490BL | 13.79 -> 13.83 | 8.48 -> 8.21 | 6.18 -> 6.75 | 5.97 -> 6.39 | 0.51 -> 0.69 |
| 12 | H230BL | 13.79 -> 14.01 | 8.48 -> 9.17 | 6.18 -> 5.97 | 5.97 -> 5.99 | 0.51 -> 0.56 |
| 12 | H200BL | 13.79 -> 14.10 | 8.48 -> 9.06 | 6.18 -> 5.90 | 5.97 -> 5.89 | 0.51 -> 0.63 |
| 12 | H280BL | 13.79 -> 14.23 | 8.48 -> 8.97 | 6.18 -> 6.27 | 5.97 -> 6.15 | 0.51 -> 0.55 |
| 10 | 540 | 15.26 -> 15.06 | 9.71 -> 9.23 | 6.55 -> 6.50 | 6.87 -> 6.91 | 0.49 -> 0.65 |
| 10 | H470BL | 15.26 -> 15.69 | 9.71 -> 9.57 | 6.55 -> 6.80 | 6.87 -> 7.00 | 0.49 -> 0.65 |
| 10 | H480BL | 15.26 -> 15.77 | 9.71 -> 9.79 | 6.55 -> 7.20 | 6.87 -> 6.79 | 0.49 -> 0.66 |
| 10 | H200BL | 15.26 -> 15.81 | 9.71 -> 9.97 | 6.55 -> 6.78 | 6.87 -> 7.44 | 0.49 -> 0.66 |
| 10 | 73227 | 15.26 -> 15.89 | 9.71 -> 10.59 | 6.55 -> 6.35 | 6.87 -> 7.13 | 0.49 -> 0.61 |
| 10 | R50XNP-BR | 15.26 -> 15.92 | 9.71 -> 10.59 | 6.55 -> 6.30 | 6.87 -> 7.26 | 0.49 -> 0.58 |
| 10 | H280BL | 15.26 -> 15.92 | 9.71 -> 9.70 | 6.55 -> 7.00 | 6.87 -> 6.91 | 0.49 -> 0.59 |
| 10 | R70 - 7957 | 15.26 -> 15.95 | 9.71 -> 10.27 | 6.55 -> 6.64 | 6.87 -> 6.84 | 0.49 -> 0.69 |
| 10 | H400BL | 15.26 -> 15.97 | 9.71 -> 9.84 | 6.55 -> 6.69 | 6.87 -> 6.91 | 0.49 -> 0.68 |
| 10 | H490BL | 15.26 -> 16.05 | 9.71 -> 9.61 | 6.55 -> 7.48 | 6.87 -> 7.34 | 0.49 -> 0.71 |
| 10 | R90 | 15.26 -> 16.08 | 9.71 -> 9.60 | 6.55 -> 6.70 | 6.87 -> 7.33 | 0.49 -> 0.75 |
| 10 | C 211 | 15.26 -> 16.38 | 9.71 -> 10.71 | 6.55 -> 6.34 | 6.87 -> 6.68 | 0.49 -> 0.55 |
| 10 | H230BL | 15.26 -> 16.42 | 9.71 -> 10.82 | 6.55 -> 6.82 | 6.87 -> 6.85 | 0.49 -> 0.61 |
| 10 | F35 | 15.26 -> 16.90 | 9.71 -> 11.04 | 6.55 -> 6.62 | 6.87 -> 6.53 | 0.49 -> 0.61 |
