Tiemco: TMC9300

Company Tiemco
www www.tiemco.co.jp
Type Single
Strength 1xh
Gape Wide
Eye Position Turned down
Shank Style Straigth
Barb Barb
Color Bronze
Usages Dry
Wet
Larva
Caddis
Nymph
Trout
Grayling
Freshwater
Spider
Soft Hackle
Sizes 18 16 14 12 10 8

Sizes

Length12.09 mm
Shank Length8.36 mm
Throat5.01 mm
Gape4.53 mm
Eye Width1.46 mm
Wire Thickness0.45 mm
Length13.98 mm
Shank Length9.15 mm
Throat5.69 mm
Gape5.60 mm
Eye Width1.56 mm
Wire Thickness0.49 mm
Length16.54 mm
Shank Length11.49 mm
Throat6.71 mm
Gape6.69 mm
Eye Width1.79 mm
Wire Thickness0.56 mm
Length19.66 mm
Shank Length12.55 mm
Throat7.40 mm
Gape7.42 mm
Eye Width2.08 mm
Wire Thickness0.63 mm

Similar hooks

Hooks found to have similar properties as this hook (matched per hook size, ordered by total length).
The left number in each column is this value for that size.

Size Hook Length Shank Length Gape Throat Wire
14 R50X-94845 12.09 -> 11.68 8.36 -> 8.23 4.53 -> 4.69 5.01 -> 5.60 0.45 -> 0.44
14 H470BL 12.09 -> 11.90 8.36 -> 8.09 4.53 -> 5.18 5.01 -> 5.03 0.45 -> 0.48
14 N 12.09 -> 12.10 8.36 -> 8.34 4.53 -> 4.42 5.01 -> 5.13 0.45 -> 0.49
14 C 211 12.09 -> 12.48 8.36 -> 8.18 4.53 -> 4.70 5.01 -> 5.15 0.45 -> 0.43
14 BL 300 12.09 -> 12.82 8.36 -> 8.65 4.53 -> 4.76 5.01 -> 4.91 0.45 -> 0.45
14 120 BL 12.09 -> 12.83 8.36 -> 8.98 4.53 -> 4.75 5.01 -> 5.12 0.45 -> 0.46
14 FW 500 - Dry Fly Traditional 12.09 -> 13.11 8.36 -> 8.33 4.53 -> 5.03 5.01 -> 5.19 0.45 -> 0.51
14 TMC108SP-BL 12.09 -> 13.12 8.36 -> 8.05 4.53 -> 4.73 5.01 -> 5.00 0.45 -> 0.47
14 AK501 12.09 -> 13.22 8.36 -> 9.23 4.53 -> 4.61 5.01 -> 4.98 0.45 -> 0.44
14 FW 501 12.09 -> 13.25 8.36 -> 8.78 4.53 -> 4.99 5.01 -> 5.23 0.45 -> 0.51
14 11001 12.09 -> 13.40 8.36 -> 8.88 4.53 -> 4.61 5.01 -> 4.88 0.45 -> 0.44
14 730 12.09 -> 13.61 8.36 -> 9.14 4.53 -> 4.86 5.01 -> 4.91 0.45 -> 0.51
14 C 231 12.09 -> 13.69 8.36 -> 9.40 4.53 -> 4.84 5.01 -> 5.30 0.45 -> 0.49
14 AK482 BL 12.09 -> 13.78 8.36 -> 9.19 4.53 -> 4.66 5.01 -> 5.73 0.45 -> 0.51
12 9485 13.98 -> 13.55 9.15 -> 9.33 5.60 -> 5.36 5.69 -> 5.57 0.49 -> 0.54
12 AK503BL 13.98 -> 13.57 9.15 -> 8.85 5.60 -> 5.47 5.69 -> 5.94 0.49 -> 0.43
12 R50X-94845 13.98 -> 13.63 9.15 -> 9.57 5.60 -> 5.51 5.69 -> 6.38 0.49 -> 0.53
12 H130BL 13.98 -> 13.70 9.15 -> 8.95 5.60 -> 5.46 5.69 -> 6.35 0.49 -> 0.47
12 H230BL 13.98 -> 14.01 9.15 -> 9.17 5.60 -> 5.97 5.69 -> 5.99 0.49 -> 0.56
12 H200BL 13.98 -> 14.10 9.15 -> 9.06 5.60 -> 5.90 5.69 -> 5.89 0.49 -> 0.63
12 H280BL 13.98 -> 14.23 9.15 -> 8.97 5.60 -> 6.27 5.69 -> 6.15 0.49 -> 0.55
12 TMC100BL 13.98 -> 14.37 9.15 -> 9.77 5.60 -> 5.47 5.69 -> 5.51 0.49 -> 0.50
12 FW 501 13.98 -> 14.38 9.15 -> 9.54 5.60 -> 5.86 5.69 -> 5.74 0.49 -> 0.56
12 FW 500 - Dry Fly Traditional 13.98 -> 14.41 9.15 -> 9.45 5.60 -> 5.76 5.69 -> 5.59 0.49 -> 0.57
12 AK501 13.98 -> 14.53 9.15 -> 10.00 5.60 -> 5.68 5.69 -> 5.44 0.49 -> 0.50
12 TMC100SP-BL 13.98 -> 14.91 9.15 -> 10.14 5.60 -> 5.55 5.69 -> 5.69 0.49 -> 0.53
12 C 211 13.98 -> 14.95 9.15 -> 10.40 5.60 -> 5.34 5.69 -> 5.60 0.49 -> 0.51
12 R72 13.98 -> 15.88 9.15 -> 10.35 5.60 -> 5.82 5.69 -> 5.44 0.49 -> 0.59
10 FW 501 16.54 -> 16.89 11.49 -> 11.48 6.69 -> 6.60 6.71 -> 6.85 0.56 -> 0.60
10 F35 16.54 -> 16.90 11.49 -> 11.04 6.69 -> 6.62 6.71 -> 6.53 0.56 -> 0.61
10 FW 560 - Traditional Nymph 16.54 -> 18.57 11.49 -> 13.09 6.69 -> 6.64 6.71 -> 6.38 0.56 -> 0.68
10 FW 561 16.54 -> 18.66 11.49 -> 12.40 6.69 -> 6.70 6.71 -> 6.53 0.56 -> 0.66
10 CK52SNP-BR 16.54 -> 18.82 11.49 -> 12.61 6.69 -> 6.96 6.71 -> 7.02 0.56 -> 0.61
8 AK881 19.66 -> 18.77 12.55 -> 12.46 7.42 -> 7.14 7.40 -> 7.38 0.63 -> 0.77
8 FW 501 19.66 -> 19.08 12.55 -> 12.87 7.42 -> 7.91 7.40 -> 7.40 0.63 -> 0.68
8 AK482 BL 19.66 -> 19.15 12.55 -> 12.44 7.42 -> 7.37 7.40 -> 7.86 0.63 -> 0.71
8 73100 19.66 -> 21.29 12.55 -> 12.98 7.42 -> 7.82 7.40 -> 7.71 0.63 -> 0.70
8 FW 561 19.66 -> 21.42 12.55 -> 14.15 7.42 -> 7.97 7.40 -> 7.62 0.63 -> 0.71
8 W228 19.66 -> 21.56 12.55 -> 13.61 7.42 -> 7.26 7.40 -> 7.56 0.63 -> 0.82
8 S82NP-BR 19.66 -> 21.60 12.55 -> 13.73 7.42 -> 7.41 7.40 -> 8.00 0.63 -> 0.81
8 SS15 19.66 -> 21.94 12.55 -> 14.23 7.42 -> 7.95 7.40 -> 8.34 0.63 -> 0.71
